PGC-300-60 Collaborative Parallel Gripper
Electrical Grippers
■ It supports plug and play with all collaborative robot brands
■ High protection level is up to IP67
■ An integrated controller design allowing the gripper to be used without an external controller
■ Intelligent feedback for monitoring gripping, rotation status and drop detection
QUANTITY
■ ■ ■ ■ ■ ■ ■ ■ ■ ■ SPECIFICATIONS
■ ■ ■ ■ ■ ■ ■ ■ ■ ■
PGC-300
| Recommended workpiece weight | 6kg |
| Repeat accuracy (positioning) | ± 0.03 mm |
| Opening/closing time | 0.8s/0.8s |
| Driving method | Precise planetary gears + rack and pinion + T-slot guide |
| Weight | 1.5kg |
| Noise emission | <50 dB |
| Communication interface | Standard: Modbus RTU (RS485), Digital I/O Optional: TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT |
| Rated voltage | 24 V DC ± 10% |
| Rated current | 0.4 A |
| Peak current | 2A |
| IP class | IP 67 |
| Recommended environment | 0~40°C, under 85% RH |
